63ZYT Motor General Specification:
Bearing: High Quality Ball Bearing
Magnet: Hard Ferrite Magnet, 2- Poles
Protection Class: IP50 （Option for IP54）
Insulation Class: Class F / Working Temperature: -40℃~+140℃
63ZYT Motor Main Technical Specification:
Model | Unit | 63ZYT01A | 63ZYT02A | 63ZYT03A | 63ZYT04A |
Rated Voltage | VDC | 24v (option for 12v up to 60vdc) | |||
Rated Speed | Rpm | 3200 | 3100 | 3000 | 3000 |
Rated Torque | N.m | 0.15 | 0.31 | 0.40 | 0.50 |
Rated Current | A | 2.8 | 5.8 | 7.0 | 9.0 |
Output Power | W | 50 | 100 | 125 | 157 |
No Load Speed | Rpm | 3600 | 3600 | 3600 | 3600 |
Weight | Kg | 1 | 1.2 | 1.35 | 1.5 |
Motor Length | Mm | 95 | 110 | 125 | 140 |
63WG Worm Gearbox Specification:
Reduction ratio | 10 | 15 | 30 | |
Efficiency | 0.65 | 0.55 | 0.45 | |
Continuous torque | Ncm | Up to 1000（metallic gears） Up to 400（non-metallic gears） | ||
Weight of gearbox | kg | 0.4 | ||
Axial load/radial load | N | 300/350 | ||
63WG.63ZYT01A Series Worm Gear Motor Specification:
Reduction ratio | 10 | 15 | 30 | |
Transmission Efficiency | 65﹪ | 55﹪ | 45﹪ | |
No Load Speed | Rpm | 360 | 240 | 120 |
Rated Speed | Rpm | 320 | 206 | 100 |
Rated Torque | N.m | 0.9 | 1.2 | 2.0 |
63WG.63ZYT02A Series Worm Gear Motor Specification:
Reduction ratio | 10 | 15 | 30 | |
Transmission Efficiency | 65﹪ | 55﹪ | 45﹪ | |
No Load Speed | Rpm | 360 | 240 | 120 |
Rated Speed | Rpm | 320 | 206 | 100 |
Rated Torque | N.m | 2.0 | 2.5 | 4.1 |
63WG.63ZYT03A Series Worm Gear Motor Specification:
Reduction ratio | 10 | 15 | 30 | |
Transmission Efficiency | 65﹪ | 55﹪ | 45﹪ | |
No Load Speed | Rpm | 360 | 240 | 120 |
Rated Speed | Rpm | 320 | 206 | 100 |
Rated Torque | N.m | 2.6 | 3.3 | 5.4 |
63WG.63ZYT04A Series Worm Gear Motor Specification:
Reduction ratio | 10 | 15 | 30 | |
Transmission Efficiency | 65﹪ | 55﹪ | 45﹪ | |
No Load Speed | Rpm | 360 | 240 | 120 |
Rated Speed | Rpm | 320 | 206 | 100 |
Rated Torque | N.m | 3.2 | 4.1 | 6.7 |
Drawing:
