80ZYT Motor General Specifications:
Bearing: High Quality Ball Bearing
Magnet: Hard Ferrite Magnet, 2- Poles
Protection Class: IP50 （Option for IP54）
Insulation Class: Class F / Working Temperature: -40℃~+140℃
80ZYT Motor Main Technical Specifications:
Model | Unit | 80ZYT01L | 80ZYT02L | 80ZYT03L | 80ZYT04L |
Rated Voltage | VDC | 24v (option for 12v up to 220vdc) | |||
Rated Speed | Rpm | 1500 | 1500 | 1500 | 1500 |
Rated Torque | N.m | 0.5 | 0.8 | 1.1 | 1.3 |
Rated Current | A | 4.5 | 7.5 | 10.5 | 12.5 |
Output Power | W | 78.5 | 125.6 | 172.7 | 204.1 |
No Load Speed | Rpm | 2000 | 2000 | 2000 | 2000 |
Weight | Kg | 2.5 | 3 | 3.5 | 4 |
Motor Length | Mm | 120 | 140 | 160 | 175 |
NMRV030.80ZYT01L Worm Gear Motor Specification:
Reduction ratio | 5 | 7.5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 | 60 | 80 | |
Transmission Efficiency | 80﹪ | 78﹪ | 75﹪ | 72﹪ | 70﹪ | 65﹪ | 60﹪ | 55﹪ | 50﹪ | 45﹪ | 40﹪ | |
No Load Speed | Rpm | 400 | 266 | 200 | 133 | 100 | 80 | 66 | 50 | 40 | 33 | 25 |
Rated Speed | Rpm | 300 | 200 | 150 | 100 | 75 | 60 | 50 | 37.5 | 30 | 25 | 18.75 |
Rated Torque | N.m | 2 | 2.9 | 3.7 | 5.4 | 7 | 8.1 | 9 | 11 | 12.5 | 13.5 | 16 |
NMRV030.80ZYT02L Worm Gear Motor Specification:
Reduction ratio | 5 | 7.5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 | 60 | 80 | |
Transmission Efficiency | 80﹪ | 78﹪ | 75﹪ | 72﹪ | 70﹪ | 65﹪ | 60﹪ | 55﹪ | 50﹪ | 45﹪ | 40﹪ | |
No Load Speed | Rpm | 400 | 266 | 200 | 133 | 100 | 80 | 66 | 50 | 40 | 33 | 25 |
Rated Speed | Rpm | 300 | 200 | 150 | 100 | 75 | 60 | 50 | 37.5 | 30 | 25 | 18.75 |
Rated Torque | N.m | 3.2 | 4.6 | 6 | 8.6 | 11.2 | 13 | 14.4 | 17.6 | 20 | 21.6 | 25.6 |
NMRV030.80ZYT03L Worm Gear Motor Specification:
Reduction ratio | 5 | 7.5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 | 60 | 80 | |
Transmission Efficiency | 80﹪ | 78﹪ | 75﹪ | 72﹪ | 70﹪ | 65﹪ | 60﹪ | 55﹪ | 50﹪ | 45﹪ | 40﹪ | |
No Load Speed | Rpm | 400 | 266 | 200 | 133 | 100 | 80 | 66 | 50 | 40 | 33 | 25 |
Rated Speed | Rpm | 300 | 200 | 150 | 100 | 75 | 60 | 50 | 37.5 | 30 | 25 | 18.75 |
Rated Torque | N.m | 4.4 | 6.4 | 8.2 | 11.8 | 15.4 | 17.8 | 19.8 | 24.2 | 27.5 | 29.7 | 35.2 |
NMRV030.80ZYT04L Worm Gear Motor Specification:
Reduction ratio | 5 | 7.5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 | 60 | 80 | |
Transmission Efficiency | 80﹪ | 78﹪ | 75﹪ | 72﹪ | 70﹪ | 65﹪ | 60﹪ | 55﹪ | 50﹪ | 45﹪ | 40﹪ | |
No Load Speed | Rpm | 400 | 266 | 200 | 133 | 100 | 80 | 66 | 50 | 40 | 33 | 25 |
Rated Speed | Rpm | 300 | 200 | 150 | 100 | 75 | 60 | 50 | 37.5 | 30 | 25 | 18.75 |
Rated Torque | N.m | 5.2 | 7.6 | 9.7 | 14.4 | 18.2 | 21.1 | 23.4 | 28.6 | 32.5 | 35.1 | 41.6 |
Drawing:
