90ZYT Motor General Specifications:
Bearing: High Quality Ball Bearing
Magnet: Hard Ferrite Magnet, 4- Poles
Protection Class: IP50 （Option for IP54）
Insulation Class: Class F / Working Temperature: -40℃~+140℃
90ZYT Motor Main Technical Specifications:
Model | Unit | 90ZYT01L | 90ZYT02L | 90ZYT03L |
Rated Voltage | VDC | 24v (option for 12v 36v 48v up to 220vdc) | ||
No Load Speed | Rpm | 2300 | 2300 | 2300 |
Rated Torque | N.m | 1.5 | 2.0 | 3.0 |
Rated Speed | Rpm | 1850 | 1800 | 1800 |
Rated Current | A | 16.5 | 21 | 32 |
Output Power | W | 290 | 377 | 565 |
Weight | Kg | 3.5 | 4 | 4.5 |
Motor Length | Mm | 155 | 180 | 199 |
NMRV040.90ZYT01L Worm Gear Motor Specification:
Reduction ratio | 5 | 7.5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 | 60 | 80 | 100 | |
Transmission Efficiency | 90% | 85% | 85% | 80% | 75% | 75% | 70% | 65% | 60% | 55% | 50% | 40% | |
No Load Speed | Rpm | 460 | 306 | 230 | 153 | 115 | 92 | 76 | 57 | 46 | 28 | 28 | 23 |
Rated Speed | Rpm | 370 | 246 | 185 | 123 | 92 | 74 | 61 | 46 | 37 | 30 | 23 | 18 |
Rated Torque | N.m | 6.8 | 9.6 | 12.8 | 18.0 | 22.5 | 28.1 | 31.5 | 39.0 | 45.0 | 49.5 | 60.0 | 60.0 |
NMRV040.90ZYT02L Worm Gear Motor Specification:
Reduction ratio | 5 | 7.5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 | 60 | 80 | 100 | |
Transmission Efficiency | 90% | 85% | 85% | 80% | 75% | 75% | 70% | 65% | 60% | 55% | 50% | 40% | |
No Load Speed | Rpm | 460 | 306 | 230 | 153 | 115 | 92 | 76 | 57 | 46 | 38 | 28 | 23 |
Rated Speed | Rpm | 360 | 240 | 180 | 120 | 90 | 72 | 60 | 45 | 36 | 30 | 22 | 18 |
Rated Torque | N.m | 9.0 | 12.8 | 17.0 | 24.0 | 30.0 | 37.5 | 42.0 | 52.0 | 60.0 | 66.0 | 80.0 | 80.0 |
NMRV040.90ZYT03L Worm Gear Motor Specification:
Reduction ratio | 5 | 7.5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 | 60 | 80 | 100 | |
Transmission Efficiency | 90% | 85% | 85% | 80% | 75% | 75% | 70% | 65% | 60% | 55% | 50% | 40% | |
No Load Speed | Rpm | 460 | 306 | 230 | 153 | 115 | 92 | 76 | 57 | 46 | 38 | 28 | 23 |
Rated Speed | Rpm | 360 | 240 | 180 | 120 | 90 | 72 | 60 | 45 | 36 | 30 | 22 | 18 |
Rated Torque | N.m | 13.5 | 19.1 | 25.5 | 36.0 | 45.0 | 56.3 | 63.0 | 78.0 | 90.0 | 99.0 | 120.0 | 120.0 |
Gear Motor Drawing:
