NMRV030.80RBL

The detailed information

80RBL Motor Main Technical Specification：

Model		80RBL-60L	80RBL-70L	80RBL-80L	80RBL-90L	80RBL-100L	80RBL-120L
Number of phase		3
Number of pole		4 （Option 8 )
Voltage	V	24v(Option for 12v 36v 48v to 230vdc)
No load speed	rpm	2500	2500	2500	2500	2500	2500
Rated torque	Nm	0.5	0.8	1.0	1.2	1.5	1.8
Rated Speed	rpm	1500	1500	1500	1500	1500	1500
Rated Current	A	4.3	7	8.8	10.5	13	16
Rated Power	W	80	126	158	190	237	285
Length	mm	60	70	80	90	100	120

NMRV030.80RBL-60L Worm Gear Motor Specification:

Reduction ratio		5	7.5	10	15	20	25	30	40	50	60	80
Transmission Efficiency		80﹪	78﹪	75﹪	72﹪	70﹪	65﹪	60﹪	55﹪	50﹪	45﹪	40﹪
No Load Speed	Rpm	500	333	250	166	125	100	83	62	50	41	31
Rated Speed	Rpm	300	200	150	100	75	60	50	37	30	25	18
Rated Torque	N.m	2	2.9	3.7	5.4	7	8.1	9	11	12	13	16

NMRV030.80RBL-70L Worm Gear Motor Specification:

Reduction ratio		5	7.5	10	15	20	25	30	40	50	60	80
Transmission Efficiency		80﹪	78﹪	75﹪	72﹪	70﹪	65﹪	60﹪	55﹪	50﹪	45﹪	40﹪
No Load Speed	Rpm	500	333	250	166	125	100	83	62	50	41	31
Rated Speed	Rpm	300	200	150	100	75	60	50	37	30	25	18
Rated Torque	N.m	3.2	4.6	6	8.6	11.2	13	14.4	17.6	20	21.6	25.6

NMRV030.80RBL-80L Worm Gear Motor Specification:

Reduction ratio		5	7.5	10	15	20	25	30	40	50	60	80
Transmission Efficiency		80﹪	78﹪	75﹪	72﹪	70﹪	65﹪	60﹪	55﹪	50﹪	45﹪	40﹪
No Load Speed	Rpm	500	333	250	166	125	100	83	62	50	41	31
Rated Speed	Rpm	300	200	150	100	75	60	50	37	30	25	18
Rated Torque	N.m	4	5.8	7.5	10.8	14	16.2	18	22	25	27	32

NMRV030.80RBL-90L Worm Gear Motor Specification:

Reduction ratio		5	7.5	10	15	20	25	30	40	50	60	80
Transmission Efficiency		80﹪	78﹪	75﹪	72﹪	70﹪	65﹪	60﹪	55﹪	50﹪	45﹪	40﹪
No Load Speed	Rpm	500	333	250	166	125	100	83	62	50	41	31
Rated Speed	Rpm	300	200	150	100	75	60	50	37	30	25	18
Rated Torque	N.m	4.8	7.0	9	12.9	16.8	19.5	21.6	26.4	30	32.4	38.4

NMRV030.80RBL-100L Worm Gear Motor Specification:

Reduction ratio		5	7.5	10	15	20	25	30	40	50	60	80
Transmission Efficiency		80﹪	78﹪	75﹪	72﹪	70﹪	65﹪	60﹪	55﹪	50﹪	45﹪	40﹪
No Load Speed	Rpm	500	333	250	166	125	100	83	62	50	41	31
Rated Speed	Rpm	300	200	150	100	75	60	50	37	30	25	18
Rated Torque	N.m	6	8.7	11.2	16.2	21	24.3	27	33	37.5	40.5	48

NMRV030.80RBL-120L Worm Gear Motor Specification:

Reduction ratio		5	7.5	10	15	20	25	30	40	50	60	80
Transmission Efficiency		80﹪	78﹪	75﹪	72﹪	70﹪	65﹪	60﹪	55﹪	50﹪	45﹪	40﹪
No Load Speed	Rpm	500	333	250	166	125	100	83	62	50	41	31
Rated Speed	Rpm	300	200	150	100	75	60	50	37	30	25	18
Rated Torque	N.m	7.2	10.5	13.5	19.4	25.2	29.2	32.4	39.6	45	48.6	57.6

Drawing
