NMRV040.80RBL

The detailed information

80RBL Motor Main Technical Specification：

Model		80RBL-60M	80RBL-70M	80RBL-80M		80RBL-90M	80RBL-100M	80RBL-120M
Number of phase		3
Number of pole		4 （Option 8 )
Voltage	V	24v(Option for 12v 36v 48v to 230vdc)
No load speed	rpm	3100	3100		3100	3100	3100	3100
Rated torque	Nm	0.5	0.8		1.0	1.2	1.5	1.8
Rated Speed	rpm	2200	2200		2200	2200	2200	2200
Rated Current	A	6.5	10.5		13	15.5	19.5	23
Rated Power	W	115	185		231	277	347	416
Length	mm	60	70		80	90	100	120

NMRV040.80RBL-60M Worm Gear Motor Specification:

Reduction ratio		5	7.5	10	15	20	25	30	40	50	60	80	100
Transmission Efficiency		80﹪	78﹪	75﹪	72﹪	70﹪	65﹪	60﹪	55﹪	50﹪	45﹪	40﹪	35﹪
No Load Speed	Rpm	620	413	310	206	155	124	103	77	62	51	38	31
Rated Speed	Rpm	440	293	220	146	110	88	73	55	44	36	27	22
Rated Torque	N.m	2	2.9	3.7	5.4	7	8.1	9	11	12.5	13.5	16	17.5

NMRV040.80RBL-70M Worm Gear Motor Specification:

Reduction ratio		5	7.5	10	15	20	25	30	40	50	60	80	100
Transmission Efficiency		80﹪	78﹪	75﹪	72﹪	70﹪	65﹪	60﹪	55﹪	50﹪	45﹪	40﹪	35﹪
No Load Speed	Rpm	620	413	310	206	155	124	103	77	62	51	38	31
Rated Speed	Rpm	440	293	220	146	110	88	73	55	44	36	27	22
Rated Torque	N.m	3.2	4.6	6	8.6	11.2	13	14.4	17.6	20	21.6	25.6	28

NMRV040.80RBL-80M Worm Gear Motor Specification:

Reduction ratio		5	7.5	10	15	20	25	30	40	50	60	80	100
Transmission Efficiency		80﹪	78﹪	75﹪	72﹪	70﹪	65﹪	60﹪	55﹪	50﹪	45﹪	40﹪	35﹪
No Load Speed	Rpm	620	413	310	206	155	124	103	77	62	51	38	31
Rated Speed	Rpm	440	293	220	146	110	88	73	55	44	36	27	22
Rated Torque	N.m	4	5.8	7.5	10.8	14	16.2	18	22	25	27	32	35

NMRV040.80RBL-90M Worm Gear Motor Specification:

Reduction ratio		5	7.5	10	15	20	25	30	40	50	60	80	100
Transmission Efficiency		80﹪	78﹪	75﹪	72﹪	70﹪	65﹪	60﹪	55﹪	50﹪	45﹪	40﹪	35﹪
No Load Speed	Rpm	620	413	310	206	155	124	103	77	62	51	38	31
Rated Speed	Rpm	440	293	220	146	110	88	73	55	44	36	27	22
Rated Torque	N.m	4.8	7.0	9	12.9	16.8	19.5	21.6	26.4	30	32.4	38.4	42

NMRV040.80RBL-100M Worm Gear Motor Specification:

Reduction ratio		5	7.5	10	15	20	25	30	40	50	60	80	100
Transmission Efficiency		80﹪	78﹪	75﹪	72﹪	70﹪	65﹪	60﹪	55﹪	50﹪	45﹪	40﹪	35﹪
No Load Speed	Rpm	620	413	310	206	155	124	103	77	62	51	38	31
Rated Speed	Rpm	440	293	220	146	110	88	73	55	44	36	27	22
Rated Torque	N.m	6	8.7	11.2	16.2	21	24.3	27	33	37.5	40.5	48	52.5

NMRV040.80RBL-120M Worm Gear Motor Specification:

Reduction ratio		5	7.5	10	15	20	25	30	40	50	60	80	100
Transmission Efficiency		80﹪	78﹪	75﹪	72﹪	70﹪	65﹪	60﹪	55﹪	50﹪	45﹪	40﹪	35﹪
No Load Speed	Rpm	620	413	310	206	155	124	103	77	62	51	38	31
Rated Speed	Rpm	440	293	220	146	110	88	73	55	44	36	27	22
Rated Torque	N.m	7.2	10.5	13.5	19.4	25.2	29.2	32.4	39.6	45	48.6	57.6	63

Drawing
