NMRV040.86BLS

The detailed information

General specification

Item	Specification
Winding type	Star
Hall effect angle	120° （Electrical angle）
Shaft run out	0.025mm
Radial play	0.06mm@450g
End play	0.08mm@450g
Max. radial force	220N@10mm from the flange
Max. axial force	60N
Insulation class	Class B
Dielectric Strength	500VDC for one minute
Insulation resistance	100MΩMin.500VDC

Technical Specification：

Model		86BLS-70L	86BLS-80L	86BLS-90L	86BLS-105L	86BLS-130L	86BLS-135L
Number of phase		3
Number of pole		8
Voltage	V	48v (Option for 12v 24v up to 320vdc)
No load speed	rpm	2500	2500	2500	2500	2500	2500
Rated torque	Nm	0.7	1.0	1.3	1.8	2.5	3.0
Rated Speed	rpm	2000	2000	2000	2000	2000	2000
Rated Current	A	4	5.6	7.3	10	14	16.8
Rated Power	W	146	210	272	377	523	628
Weight	Kg	1.7	2.1	2.5	3.1	4.1	4.3
Length	mm	70	80	90	105	130	135

NMRV040.86BLS-70 Worm Gear Motor Specification:

Reduction ratio		5	7.5	10	15	20	25	30	40	50	60	80	100
Transmission Efficiency		80﹪	78﹪	75﹪	72﹪	70﹪	65﹪	60﹪	55﹪	50﹪	45﹪	40﹪	35﹪
No Load Speed	Rpm	500	333	250	166	125	100	83	62	50	41	31	25
Rated Speed	Rpm	400	266	200	133	100	80	66	50	40	33	25	20
Rated Torque	N.m	2.8	4	5.2	7.5	9.8	11.3	12.6	15.4	17.5	18.9	22.4	24.5

NMRV040.86BLS-80 Worm Gear Motor Specification:

Reduction ratio		5	7.5	10	15	20	25	30	40	50	60	80	100
Transmission Efficiency		80﹪	78﹪	75﹪	72﹪	70﹪	65﹪	60﹪	55﹪	50﹪	45﹪	40﹪	35﹪
No Load Speed	Rpm	500	333	250	166	125	100	83	62	50	41	31	25
Rated Speed	Rpm	400	266	200	133	100	80	66	50	40	33	25	20
Rated Torque	N.m	4	5.8	7.5	10.8	14	16.2	18	22	25	27	32	35

NMRV040.86BLS-90 Worm Gear Motor Specification:

Reduction ratio		5	7.5	10	15	20	25	30	40	50	60	80	100
Transmission Efficiency		80﹪	78﹪	75﹪	72﹪	70﹪	65﹪	60﹪	55﹪	50﹪	45﹪	40﹪	35﹪
No Load Speed	Rpm	500	333	250	166	125	100	83	62	50	41	31	25
Rated Speed	Rpm	400	266	200	133	100	80	66	50	40	33	25	20
Rated Torque	N.m	5.2	7.6	9.7	14	18.2	21.1	23.4	28.6	32.5	35.1	41.6	45.5

NMRV040.86BLS-105 Worm Gear Motor Specification:

Reduction ratio		5	7.5	10	15	20	25	30	40	50	60	80	100
Transmission Efficiency		80﹪	78﹪	75﹪	72﹪	70﹪	65﹪	60﹪	55﹪	50﹪	45﹪	40﹪	35﹪
No Load Speed	Rpm	500	333	250	166	125	100	83	62	50	41	31	25
Rated Speed	Rpm	400	266	200	133	100	80	66	50	40	33	25	20
Rated Torque	N.m	7.2	10.5	13.5	19.4	25.2	29.2	32.4	39.6	45	48.6	57.6	63

NMRV040.86BLS-130 Worm Gear Motor Specification:

Reduction ratio		5	7.5	10	15	20	25	30	40	50	60	80	100
Transmission Efficiency		80﹪	78﹪	75﹪	72﹪	70﹪	65﹪	60﹪	55﹪	50﹪	45﹪	40﹪	35﹪
No Load Speed	Rpm	500	333	250	166	125	100	83	62	50	41	31	25
Rated Speed	Rpm	400	266	200	133	100	80	66	50	40	33	25	20
Rated Torque	N.m	10	14.6	18.7	27	35	40.6	45	55	62.5	67.5	80	87.5

NMRV040.86BLS-135 Worm Gear Motor Specification:

Reduction ratio		5	7.5	10	15	20	25	30	40	50	60	80	100
Transmission Efficiency		80﹪	78﹪	75﹪	72﹪	70﹪	65﹪	60﹪	55﹪	50﹪	45﹪	40﹪	35﹪
No Load Speed	Rpm	500	333	250	166	125	100	83	62	50	41	31	25
Rated Speed	Rpm	400	266	200	133	100	80	66	50	40	33	25	20
Rated Torque	N.m	12	17.5	22.5	32.4	42	48.7	54	66	75	81	96	105

Gear Motor Dimensions
